The CPQ -CE-SR-CDF02 is a four-channel multimode QSFP28 transceiver designed for 100 Gigabit
Ethernet and high-speed interconnect applications. Each channel uses an 850nm VCSEL transmitter and
a PIN photodiode receiver and supports 25.78Gbps which provides an aggregated 103.125Gbps full
duplex link.
The module supports up to 70 meters on OM3 multimode fiber and up to 100 meters on OM4 fiber. It
follows the QSFP28 Multi -Source Agreement and supports Digital Diagnostics Monitoring. The
transceiver operates from a single 3.3V supply and integrates an MPO optical interface for parallel
transmission.
The product is suitable for 40GBASE-SR4, 100GBASE-SR4 systems, server to server connectivity, high
performance computing clusters and short reach connections between switches, routers or transport
equipment.
